Type 5B - Five-roll expanders with adjustable reach for expanding thin wall tubes of stainless steel and titanium alloys.

Type

Used for tubes (outside diameter and wall thickness)

Expanding range (min.-max.), mm

Operative roll length, L mm

Reach, mm

Size square on mandrel, mm

5B-26-31-40

28х1; 29х1,5

25,0 – 27,7

31

22 - 40

14

5B-27-31-40

30х1,5

26 - 29,2

5B-28-31-40

30х1

27 – 30,2

5B-29-31-40

32х1,5

28,0 - 31,2

5B-30-31-40

33х1,5

29,0 – 32,4

5B-32-31-40

35х1,5

30,0 - 34,8

5B-33-31-40

38х2,5

32,0 - 36,8

5B-34-31-40

38х2

5B-35-31-40

38х1,5

34,0 - 37,6

5B-38-31-40

42х2

36,0 - 40,8

19

5B-39-31-40

42х1,5

37,8 - 43,6

5B-41-47-57

45х2

40,0 - 45,0

47

40 - 57

5B-42-47-57

45х1,5

5B-48-47-57

51х1,5

46,0 – 51,0
