Type G – with adjustable bearing stop – for expanding with flanging in furnace doubles.


Type

Used for tubes (outside diameter and wall thickness)

Expanding range (min.-max.), mm

Flanging range (min.-max.), mm

Reach, mm

Size square on mandrel, mm

G-(73-76)-77-77

102х13; 89х6; 89х8

69,1 - 84,5

81,3 - 96,6

77

27

G-(77-82)-77-77

102х10; 102х12; 89Х6

73,4 - 88,6

85,5 - 100,6

G-(82-86)-77-77

102х8; 102х10

77,7 - 92,6

89,8 - 104,6

G-(86-90)-77-77

102х6; 102х8

82,3 - 97,6

94,5 - 109,6

G-(98-77)-77

110х6; 114х8

93,7 - 104,7

105,8 - 116,7

G-103-77-77

127х12

97,5 - 110,6

109,4 - 122,4

G-(107-111)-77-77

127х8; 127х10

101,5 - 118,6

113,4 - 130,4

G-126-77-77

152х13

121,3 - 133,8

133,3 - 145,8

G-(132-136)-77-77

152х8; 152х10

127,4 - 142,9

139,4 - 154,9

G-(133-139)-77-77

159х10; 159х13

128,0 - 146,5

140,0 - 158,5
