The core drill with a guiding part for drilling tubes


The core drill Z pilot designed for drilling tubes

For reducing expanded part of tube wall without damaging the tube sheet.

Зенкер типа З

The table shows the most common core drill. It is possible to manufacture core drills for other tube sizes upon request.

Размеры в миллиметрах



Tool no.

NominalTube O.D.mm

NominalWall Thicknessmm

Z – 20-25

20

2,5

Z – 20-20

2,0

Z – 25-30

25

3,0

Z – 25-25

2,5

Z – 25-20

2,0

Z – 38-35

38


3,5

Z – 38-30

3,0

Z – 38-25

2,5

The core drill ZSH for removing weld in combined joints

Designed for removing weld in combined joints without damaging the tube sheet.



Зенкер типа ЗШ

The table shows the most common core drill. It is possible to manufacture core drills for other tube sizes upon request.

Размеры в миллиметрах

Tool no.

NominalTube O.D.mm

ZSH -20

20

ZSH -25

25

ZSH -38

38
