A Type – cooled (With fixed reach)

A Type – cooled (With fixed reach)

The air-oil emulsion is supply into the nozzle and exits the through body the grooves to the rollers.

Type	Used for tubes (outside diameter and wall thickness)	Expanding range (min.-max.), mm	Reach, mm	Size square on mandrel, mm
А-15-24-21	18х1,5; 19х2; 20х2,5	14,2 – 16,8	21	10
А-16-24-21	19х1,5; 20х2; 22х3	15,2 - 17,8	21
А-19-32-29	22х1,5; 25х3	18,2 - 20,8	29
А-20-32-29	24х2; 25х2,5	19,2 - 21,8
А-21-32-29	24х1,5; 25х2	20,2 - 22,8

Manufacture other sizes of expanders – in-order.
