Tube expanding and rolling machine for heat exchangers

Tube expanding machines and machines TECHREMEX manufactured in accordance with the requirements of GOST R 55601-2013, STO 00220368-014-2009,  STO 26-17-01-83 reissue in 2007.

Specification tube expanding machines

Model

Tube position

voltage

TubeO.D.mm.

Frame

Telescopic shaft

Torquelimitation

Optionaloperations

Max.weight kg

machine MER-11M

horizontal

380

16 - 63

+

+

+

-

400



machine MER-16M

mobile

horizontal

380

16 - 38

+

+

+

-

160



machine MER-16M

portable

horizontal

380

16 - 38

+

+

+

-

70

17 1)

machine MER-13

vertical

380

19 - 38

+

-

+

-

250

The notices:

  1. Maximum weight of any separate part.

Specification tube expanding machines

Model

Tube position

voltage

TubeO.D.mm

Frame

Telescopic shaft

Torquelimitation

Optionaloperations

Max.weight kg



Machine

MER-16M-1

any

220

8 - 25

-

-

+

-

30

11 1)



Machine

MER-16M-2

any 220 8 - 25 - - + -

11

3,8 1)

Machine

horizontal

42 (3F)

89 - 159

-

-

-

-

40

The notices:


1) Weight of geared motor.



Tube expanding machine MER-11M

Tube expanding machine MER-11M

Tube expanding machine MER-11M  Video. DOWNLOAD  Maximum tube sheet O.D. which can be done without repositioning of the machine at the heat exchanger : 1900...

Auto tube expanding machine МER-16M

Auto tube expanding machine МER-16M

Auto tube expanding machine МER-16M  Video. DOWNLOADMaximum tube sheet O.D. which can be done without repositioning of the machine at the heat exchanger : 1500...

Portable TUBE EXPANDING MACHINE МER-16M

Portable TUBE EXPANDING MACHINE МER-16M

 Portable TUBE EXPANDING MACHINE МER-16M  Available for steel tubes from 16 mm to 38 mm O.D.Maximum tube sheet O.D. which can be done without repositioning of...

Auto tube expanding machine МER-16M-1

Auto tube expanding machine МER-16M-1

Available for steel tubes from 14 mm to 25 mm O.D.Dimensions : L 750 mm х W 500 mm х H 300 mmTHE MAIN NODELS OF AUTO TUBE EXPANDING MACHINE МER-16M-11. Mobile...

Auto tube expanding machine МER-16M-2

Auto tube expanding machine МER-16M-2

TUBE EXPANDING MACHINE MER-16M-2Available for steel tubes from 8 mm to 25 mm O.D.Specifications   video Tube expanding machine. DOWNLOAD- Dimensions...

TUBE EXPANDING MACHINE МER-16M-3-24

TUBE EXPANDING MACHINE МER-16M-3-24

Available for steel tubes from 8 mm to 16 mm O.D.Safe voltage, low noise, compact size, and the possibility of long continuous operation make this machine necessary...

TUBE EXPANDING MACHINE МER-16M-3-48

TUBE EXPANDING MACHINE МER-16M-3-48

Available for steel tubes from 16 mm to 42 mm O.D. Suspension using a balance beam.Safe voltage, low noise, compact size, and the possibility of long continuous...
