TUBE EXPANDING MACHINE МER-16M-3-24

Available for steel tubes from 8 mm to 16 mm O.D.

Safe voltage, low noise, compact size, and the possibility of long continuous operation make this machine necessary for large volumes of work, especially inside chambers.
The control unit CU based on the programmable logic controller (PLC) Segnetics. It is serve to control the MR using a special BLD driver that provides smooth start of the MR and high-precision torque control. CU have connector RS 232 to connect to the computer. CU organizes a series of expanding: start the engine, testing to the specified torque, stop, reverse activation. In automatic mode, the cycles are repeating. The duration of the pause between cycles is adjustable.

• Power supply: 220 V, 50 Hz
• Power output: no more than 300 Watts
• Dimensions: 300х320х170 mm
• Weight: no more than 10 kg Geared motor MR made on the base of the engine with a safe voltage of 24 V.
• Power output: 120 Watts
• Weigh: no more than 2,9 kg
•  Dimensions: 210х70х210 mm

The control key placed directly on the gear motor.

A spring balancer provide for suspension to compensate for the weight of the gear motor.
Main technical characteristics of the CU and additional equipment on request (see the
description of the machine MER-16M-2)

 Gear motor MR
