Auto tube expanding machine МER-16M-1


Available for steel tubes from 14 mm to 25 mm O.D.

Dimensions : L 750 mm х W 500 mm х H 300 mm

THE MAIN NODELS OF AUTO TUBE EXPANDING MACHINE МER-16M-1

1. Mobile stand with a work desk and a wardrobe for snap

2. Geared motor MR

3. Tool balancer TSW

4. Leg three-button remote control

Geared motor MR

Geared motor no.

Speed rpm

Torque, H х m

The size of the internal square of the lock, mm

Range of expanded tubes
non-ferrous metals steel
MR-370-281 280 - 670 2 - 16 10 8x1 - 19x1,5 8x1 - 16x1,5
MR-370-180 180 - 430 3 - 25 10 10x1 - 25x1,5 10x1 - 20x2
MR-370-102 102 - 210 4 - 46 10 12x1 - 30x1 12x1 - 25x2,5
MR-370-88 90 - 210 4 - 53 10 12x1 - 32x1,5 12x1 - 25x3



Power supply: 220 V, 50 Hz

Power output: 370 watts

Weight : 11 kg

Most components are manufactured in Germany and Italy. Certified according to GOST R.
