Auto tube expanding machine МER-16M

Auto tube expanding machine МER-16M

  Video. DOWNLOAD

Maximum tube sheet O.D. which can be done without repositioning of the machine at the heat exchanger : 1500 mm

Control Unit, Geared motor , Telescopic Universal Shaft identical machine MER-11M.

AUTO TUBE EXPANDING MACHINE МER-16M

The distinctive design of the stand of the МЭР-16М machine provides a significant advantage in operation, increases mobility and ease of use.

 Application practice has shown high reliability, accuracy and repeatability of torque development, durability of МЭР-16М machines.

Designed for expanding tubes with a O.D. diameter of 16 to 38 mm

Maximum tube sheet O.D., which can be done without repositioning of the machine at the heat exchanger: 1500 mm

Overall dimensions: 950x800x1450 mm

Weight: 160 kg.

The optimum speed is set automatically depending on the set torque.

 THE CONTROL UNIT, GEAR MOTOR, TELESCOPIC SHAFT*, ADDITIONAL EQUIPMENT ON REQUEST, COOLING AND LUBRICATION UNIT ARE IDENTICAL TO THE MACHINE MER-11M.

                                                                                                                                                   THE MAIN COMPONENTS OF AUTO TUBE EXPANDING machine МER-16M

1. Mobile stand with a work desk and a wardrobe for snap.
2. The control unit is adapted to a programmable logic controller (PLC) Signetics.
3. Geared motor MR (Italy) controlled by a control unit with frequency Converter.
4. Telescopic shaft VT with one hinge.
5. Tool balancer TSW.
6. Leg three-button remote control.
7. Tube expanding tool type “A” – cooled.

Additional equipment option: the machine of cooling and lubrication.

                                                                                                                                                    The optimal mode of expanding

The optimal mode of expanding, adjustable control unit with ACUTP of expanding meets the requirements of GOST R 55601-2013, OST 26-17-83* (reprint from 2007), and expanders, manufactured by OST 26-17-83** (reprint from 2008) and STO 00220368-015-2009***, provides high quality expanding machine the critical deviation parameters. For example, for tubes size 25x2-2.5 mm permitted limit deviation of the outer diameter of the tube to ±0.45 mm, wall thickness up to 15% of the diameter clearance between the tube and the hole in the tube sheet to 1.58 mm.

The optimal mode of expanding MER-16 was produced from 1998 to 2009. Since 2010, produced an upgraded machine MER-16M.

All units MER-16 and MER-16M (over 40), even released over ten years ago work today.

Most components are manufactured in Germany and Italy. Certified according to GOST R.

                                                                                                                                                      We would like to be useful to Your business.
